Description

Geekvape Z (Zeus) Subohm Tank 5

CLASSIC REBORN
EXPERIENCE REDEFINED

• Enhanced Flavour (Up to 60ml Coil Life)

• Top Push Fill (Cleaner, Simpler)

• Top Airflow Leak-Resistant

• Best for DTL

• Z XM Coil (Boost Version) Upgrade


The GeekVape Z (Zeus) Sub-Ohm Tank 5, engineered for ultimate flavor, massive vapor, and reborn with true leak resistance. Featuring top adjustable airflow, top push-to-fill, and upgraded Z XM Boost Version coils with up to 60mL coil life. Perfect for DTL vapers seeking durability, performance, and smooth, consistent hits every time.

SHINING STRONG

• Classic Design Speaks Power


TOP PUSH FILL - CLEANER, SIMPLER

• Completely hassle-free — with a cap that stays attached, never lost.


TOP AIRFLOW, TAILORED FLAVOUR

• Adjust the airflow, feel the difference — every draw made just for you.


ENHANCED FLAVOUR UP TO 60ML COIL LIFE

• Paired with the Z XM Coil (Boost Version), it maximizes atomization efficiency for upgraded flavour, while extending coil life up to 60mL for lasting performance.


COMPATIBLE WITH

Z XM COIL (BOOST VERSION)

• Z0.4 XM Coil (Boost Version) | 0.4ohm 50-60W

• Z0.2 XM Coil (Boost Version) | 0.2ohm 70-80W

• Z0.15 XM Coil (Boost Version) | 0.15ohm 70-85W


Z SERIES COILS

• Z0.4 Coil 0.4ohm KA1 | Power Range: 50-60W

• Z0.2 Coil 0.2ohm KA1 | Power Range: 70-80W

• Z0.15 Coil 0.15ohm KA1 | Power Range: 80-90W


TANK USER GUIDE

FILL/REFILL THE E-LIQUID

• Open the fill port: Slide the top-fill cap in the direction of the arrow until the fill hole is fully exposed.

• Fill with e-liquid: Insert the bottle nozzle into the hole, gently squeeze, and fill slowly.


Pay attention and do not overfill.

• Close the fill port: Push the cap back into place.

• Prime the coil: If installing a new coil, wait 3-5 minutes after filling to allow the cotton to fully saturate. (Skip this step when only refilling.)


TANK TUBE REPLACEMENT

• Unscrew to remove the bottom hardware.

• Gently push out the old glass tube. Dispose of glass products properly in accordance with local regulations, and take care not to injure yourself or others during the process.

• Install the new glass tube into the tank.

• Screw the bottom hardware back onto the tank.


TIPS: When replacing the glass tube, check the position of the sealing ring to ensure it is correctly installed. If the sealing ring is worn, replace it with the spare one provided in the package to prevent leakage.

CHANGE THE COIL
Under these circumstances you will need to replace the coil following guidance:

• when you notice the flavour starts to deteriorate or taste burnt.

• when you want to try a new flavour of E-liquid.

• when E-liquid is stored in the tank chamber for too long (usually over 2 weeks)


and the colour deepens (E-liquid may have oxidized over time).

• Turn the tank upside down, then rotate the base counterclockwise to remove it.

• Use the toolkit included in the package to remove the old coil. If you wish to completely remove any residual e-liquid from the tank, rinse it with water and allow it to air dry before.

• Reattach the base by rotating it clockwise and ensure it is securely locked.


SPECIFICATIONS

• Dimensions: 29 * 56.1mm

• E-Liquid Capacity: 5.5ml (Pre-Installed)

• Drip Tip: 810 Replaceable

• Airflow Method: Top Adjustable Airflow for Minimum Leak Risk

• Compatible Coil: Z Series Coils & Z XM Coil (Boost Version)


PACKAGE INCLUDES

• 1 x Geekvape Z Subohm Tank 5

• 1 x Z0.2 XM Coil (Boost Version 70-80W) (Pre-Installed)

• 1 x Z0.4 XM Coil (Boost Version 50-60W) (Spare)

• 1 x Glass Tube (Spare)

• 1 x Coil Tool

• 1 x Manual Warning & Info Cards

Pros and cons

• Sustainably produced in ISO7 Lab conditions.
• May discolor in direct sunlight
